Application Case of HeTai Motor in Medical Peristaltic Pumps
Development Prospects
Technology Upgrade Trends:
Smart control and miniaturized design are becoming mainstream.
42mm/57mm compact motors can be adapted to portable medical devices (e.g., infusion pumps, dialysis machines), meeting lightweight and high-efficiency demands.
Policy Drivers:
Global medical device certification standards (e.g., FDA, CE) are becoming stricter.
HT Motor’s high-reliability design complies with medical device certification requirements, helping customers expedite approvals.
Performance Advantages
1. High-Precision Control:
Stepper motors use closed-loop control algorithms, achieving flow error ≤ ±0.5%—ideal for microliter-level filling of freeze-dried powders.
Brushless motors enable stepless speed adjustment via PWM, ensuring precise flow control for various liquid viscosities.
2. Low Noise & Energy Efficiency:
Optimized electromagnetic design reduces operating noise ≤45dB, suitable for cleanroom environments.
Current range: 0.4A~7A, with energy-saving mode, reducing power consumption by 30% compared to traditional motors.
3. Lightweight & Durability:
Motor weight ≈1kg, compatible with portable devices.
High-temperature-resistant materials + IP66 protection, ensuring stable operation in humid & high-temperature environments.
HT’s Core Competitiveness
1. Patent Technology Support:
"Stepper Motor Endurance Test Device" patent ensures stable performance under long-term high loads, extending lifespan by 30%.
Self-developed "Motor Rotation Tester" enables multi-dimensional checks (torque, vibration, etc.), ensuring ≥99.9% factory pass rate.
2. Customization Capabilities:
Wide voltage range (1.62~48V) and support for RS485/Modbus protocols, meeting smart medical device integration needs.
3. Supply Chain & Cost Advantages:
Localized production in Changzhou (West Taihu Science Park) shortens lead times.
Economies of scale reduce unit costs, saving customers 15% in total costs.
4. Certifications & Reputation:
ISO 13485 Medical Device QMS certified.
Trusted by top-tier hospital equipment suppliers, with end-user feedback:
"Maintenance cycles extended to 8,000 hours, significantly reducing operational costs."
Application Case of Frameless Motor
Industrial Assembly Robotic Arm
Core Advantages
Ultra-high Torque (7.5 N.M): Meets the precision assembly requirements of heavy-duty automotive components (e.g., chassis, powertrain).
Compact Height (45mm): Adapts to modular robotic arm design, minimizing space occupancy.
High Speed (3000 RPM): Increases production line efficiency to 15 seconds/station, enabling 24/7 continuous operation.
Ultra-light Weight (0.22 kg): Helps FAIR Robotics' collaborative robot achieve a total weight of 8 hours, ideal for logistics and warehouse sorting.
Compliant Control (0.18 N.M): Certified by ISO 13849, with collision detection response time
Lawn mower case
This article will share the "key component" for controlling the motion of a lawn mower robot - the lawn mower motor, and how to play its role on different types of service robots.
----The current importance and future development space of lawn mowers
Lawn mowers play an important role in improving work efficiency, improving environmental aesthetics, promoting the development of mechanization technology, and environmental protection and energy conservation. With the promotion of trends such as intelligence, energy conservation and environmental protection, as well as personalized needs and the expansion of the international market, the lawn mower industry will usher in a broader development space.
With the rapid advancement of technology, the field of lawn mowers has ushered in significant development, and various types and feature-rich lawn mowers have emerged, such as hand-push, self-driving, four-wheel drive, and zero-turn types. These innovations not only enrich the market choices, but also promote the increasingly enhanced functions of accessory products to meet the diverse needs of users.
---Types of lawn mowers and motor performance requirements for lawn mowing robots
------Brushless motor: the "key part" of the robot
The intelligent power heart brushless mowing engine integrates the most advanced technology and is specially designed for efficient and precise mowing operations. It not only has powerful power output, but also integrates intelligent control technology, allowing the lawn mower to still operate with ease in complex and changeable outdoor environments, showing extraordinary performance and stability.
1. Small size, light weight and high output power.
2. High efficiency, high relative density of output power and torque.
3. The speed adjustment range is wide and can operate in most working places.
4. Simple structure, reliable operation and convenient maintenance.
----Selection recommendation
Mode
Kind
No. of
Phase
No.of
Poles
Features
Rated
Voltage
Rated
Speed
Rated
Current
Output
Power
Height
Dimmer
(VDC)
(RPM)
(Amps)
(Watts)
(mm)
(mm)
36BLY01A-001AG76
Robot wheel
3
4
With Hall and reduction gearbox
24
7100
2.0
22
84.0
36
42BLY204-009AG54
18
3000
2.0
25
120
42
57BL237
Cuts
No hall
18
3290
4.0
48
53.0
57
57BL371
18
3290
4.0
48
63.5
57
57BL319
24
3290
4.0
48
63.5
57
57BL03B-035
Connedion wheel
24
3150
3.4
46
65.0
57
57BL427
24
3500
5.0
88
77.0
57
57BL432
Hall
18
3000
5.5
69
73.5
57
----Automatic mowing motor supplement
1.At present, the automatic mowing motor is basically powered by lithium batteries. Therefore,
the voltage of the motor is divided into two categories: one is 18V and the other is 24V.
2.The product range is divided into: travelling motors, cutting motors and height-adjusting motors.
3.There are three options for cranking up motors: brushed geared motors; stepper linear motors;
and brushless motors.
---Customer case sharing
To enhance motor performance according to customer needs in special environmental scenarios:
1 Waterproof performance to cope with environments such as grass dew.
2 Climbing ability ensures stable operation on a slope of approximately 30°.
3 Escape function, it can automatically escape when it is entangled in grass.
At the same time, according to customer needs, the motor structural design is optimized to meet the above usage requirements.
---Related products
Gearbox that can be used with motors
Download data sheet of↓
PG52A-PM-ST.pdf ,PG52A-ZA-HT.pdf ,PG60A-PM-ST.pdf,PG42A-PM-ST.pdf ,PG65A-ZA-HT.pdf
